7 Tag Data Link Functions
7-20
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
This section describes the procedure to set tag data links (i.e., connection information). For data links
between Controllers, the connection information is set only in the originator, i.e., the node that receives
data.
7-2-2 Tag Data Link Setting Procedure
1 Create the network configuration.
(1) Register all built-in EtherNet/IP ports for which to cre-
ate connections in the EtherNet/IP Network Configura-
tion Pane. (Refer to 7-2-3 Registering Devices.)
* If a system has already been installed, connect online to the
EtherNet/IP network and upload the network configuration.
(Refer to 7-2-10 Uploading Tag Data Link Parameters.)
↓
2 Create the tag and tag set connections.
Set the connections with one of the following methods.
(1) Basic Operation:
1.Create tags and tag sets for all registered devices (built-in Eth-
erNet/IP ports). (Refer to 7-2-4 Creating Tags and Tag Sets.)
2.Create a connection for the originator device (i.e., the
registered device that receives data as input data). (Refer to 7-
2-5 Connection Settings.)
(2) Create the connections by dragging registered
devices. (Refer to 7-2-10 Uploading Tag Data Link
Parameters.)
↓
3 Download the tag data link parameters. (Refer to 7-2-9
Downloading Tag Data Link Parameters.)
↓
4 Make sure that the tag data links are operating normally by
using the indicators for the built-in EtherNet/IP port (refer
to 15-1 Overview of Errors) and the Network Configurator
monitor functions. (Refer to 14-1 Communications
System.)
↓
5 Make sure that the output tag data is updated in the input
tags by using the Sysmac Studio’s Watch Tab Page.
Note Refer to the Sysmac Studio Version 1 Operation Manual (Cat. No.
W504) for the procedure.
