Omron Sysmac NJ-series User Manual

1-11
1 Introduction
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
1-3 Built-in EtherNet/IP Port
1
1-3-2 Part Names and Functions
 NX701 CPU Unit
Ethernet Address Notation
A specific Ethernet address is allocated to each device connected to the Ethernet network.
The built-in EtherNet/IP port's address is listed in 12-digit hexadecimal in the place shown below on
the CPU Unit.
1-3-2 Part Names and Functions
Parts and Names
Indicators
USB port
Built-in EtherNet/IP
port 1
Built-in EtherNet/IP
port 2
Built-in
EtherCAT
port
PORT1 EtherNet/IP
PORT2 EtherNet/IP
PORT3 EtherCAT
RUN
ERROR
BUSY
SHTDWN
NET RUN
PORT1
EtherNet/IP
NET ERR
LINK/ACT
SD PWR
SD BUSY
NET RUN
PORT2
EtherNet/IP
PORT3
EtherCAT
NET ERR
LINK/ACT
NET RUN
NET ERR
LINK/ACT
LOT NO. DDMYY xxxx Ver.2.00
PORT1 MAC ADDRESS:
PORT2 MAC ADDRESS:
Ethernet addresses
