13-2 Procedure to Use the SNMP Agent
1 Make the basic settings.
Refer to 1-5 EtherNet/IP Communications Procedures for the flow of basic operations.
2 Select Built-in EtherNet/IP Port Settings from the Controller Setup on the Sysmac Studio,
and then set the following on the SNMP Settings Display or SNMP Trap Settings Display.
• SNMP Service
• Recognition 1
• Recognition 2
3 Select Transfer to Controller from the Controller Menu and click the Yes Button. The built-in
EtherNet/IP port settings are transferred to the CPU Unit.
The following Built-in EtherNet/IP Port Settings are made from the Sysmac Studio to use the SNMP
agent.
13-2-1 Procedures
13-2-2 Settings Required for the SNMP Agent
Tab page Setting Setting conditions Reference
SNMP Settings SNMP service Required. page 5-10
Port No. Specified by user.
Note Required to change from the
default value of 161.
Contact, location Specified by user.
Send a recognition trap Specified by user.
Select this check box to send a recogni-
tion trap if there is access from an SNMP
manager that is not specified (Access
other than Recognition 1 and 2).
Recognition 1 and Rec-
ognition 2
Specified by user.
Make these settings to permit access by
only certain SNMP managers.
page 5-11
IP address
Host name
Community
name
