Omron Sysmac NJ-series User Manual

13-23
13 SNMP Agent
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
13-2 Procedure to Use the SNMP Agent
13
13-2-2 Settings Required for the SNMP Agent
Additional Information
Make the settings in the SNMP Settings Dialog Box and SNMP Trap Dialog Box if the SNMP
agent is used.
Refer to 5-5 SNMP Settings Display for information on the SNMP Settings Dialog Box. Refer to
5-6 SNMP Trap Settings Display for information on the SNMP Trap Dialog Box.
SNMP Trap Settings SNMP trap Required. page 5-12
Port No. Specified by user.
Note Required to change from the
default value of 162.
Trap 1 and trap 2 page 5-13
IP address Required.
Set an IP address or a host name as the
SNMP trap destination.
Host name
Community
name
Specified by user.
Version Required.
Set the version of the SNMP manager.
Tab page Setting Setting conditions Reference
