Omron Sysmac NJ-series User Manual

3-33
3 System-defined Variables Related to the Built-in EtherNet/IP Port
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
3-3 Specifications for Individual System-defined
Variables
3
3-3 Specifications for Individual System-
defined Variables
The specifications for each system-defined variable are given as described below.
 Functional Classification: EtherNet/IP Communications Errors
Variable name This is the system-defined variable name. The prefix
gives the category name.
Members The member names are given for
structure variables.
Meaning This is the meaning of the variable. Global/local Global: Global variable, Local: Local
variable
Function The function of the variable is described.
Data type The data type of the variable is given. Range of values The range of values that the vari-
able can take is given.
R/W access R: Read only,
RW: Read/write
Retained The Retain attri-
bute of the vari-
able is given.
Network Publish The Network Publish attribute of the
variable is given.
Usage in user program Whether you
can use the vari-
able directly in
the user pro-
gram is speci-
fied.
Related instruc-
tions
The instructions that are related to the variable are given.
If you cannot use the variable directly in the user program, the instructions
that access the variable are given.
Variable name _EIP_ErrSta
Meaning Built-in EtherNet/IP Error Global/local Global
Function This is the error status variable for the built-in EtherNet/IP port.
NX-series CPU Units: Represents the collective status of the following error flags.
• _EIP1_PortErr (Communications Port1 Error)
• _EIP2_PortErr (Communications Port2 Error)
• _EIP1_CipErr (CIP Communications1 Error)
• _EIP2_CipErr (CIP Communications2 Error)
• _EIP_TcpAppErr (TCP Application Communications Error)
NJ-series CPU Units: Represents the collective status of the following error flags.
• _EIP_PortErr (Communications Port Error)
• _EIP_CipErr (CIP Communications Error)
• _EIP_TcpAppErr (TCP Application Communications Error)
Note Refer to Meanings of Error Status Bits for the meanings of the error status bits.
Data type WORD Range of values 16#0000 to 16#00F0
R/W access R Retained Not retained. Network Publish Published.
Usage in user program Possible. Related instruc-
tions
You can access this variable from the user program with the following
instruction.
• GetEIPError
