7 Tag Data Link Functions
7-74
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
If the network configuration file that you want to read is not displayed, change to another folder.
2
If you select the network configuration file that you want to read, that file name is displayed in
the File name Field.
3
Click the Open Button to read the network configuration file.
4
The Network Configurator’s Title Bar will display the name of the file that was read.
5
Select any of the options as necessary. The options are listed below.
The save format will depend on the Network Configurator version. You can import configuration
files (*.ncf) created with the Network Configurator for EtherNet/IP (version 2 or lower) if you
select External Data - Import from the File Menu.
Setting Description
Select target network Allows you to select specific networks from the network configuration
and open them.
Add to current document Allows you to add the networks from the network configuration file
that is currently open to the current configuration file.
To Next Page
