8-2 CIP Messaging Communications Client Function
8
8-2-5 Request Path (IOI)
2 Input a value for each standard structure variable member.
Input the following values into the communications parameters that were registered as mem-
bers of the standard structure variable.
 When an Extension Structure Variable Is Used
Example: Using an extension structure variable to input values into RqPath (Request Path) for the
CIPSend instruction
1 Create an extension structure variable.
To use an extension structure variable to input values into RqPath (Request Path) for a CIP
communications instruction, first you need to create an extension structure user-defined vari-
able.
When you create a variable in a variable table, select the pre-registered extension structure
(_sREQUEST_PATH_EX) for a CIP communications instruction.
Member name of RqPath data type
Variable name
MOVE
EN
IN1
2
3
TRUE A . isAttributeID
A. ClasslD
A . InstancelD
OUT1
MOVE
EN
IN1 OUT1
MOVE
EN
IN1 OUT1
1 A . AttributelD
MOVE
EN
IN1 OUT1
InstanceID
(Instance ID)
Create variable A with a variable with
the extension structure (_sREQUEST_PATH_EX).
CIP communications instruction
Variable A
CIPSend
RqPath
(Request Path)
RqPath data type
Value
ClassID
(Class ID)
Member
AttributeID
(Attribute ID)
_8BIT
3
256
_16BIT
isAttributeID
(Attribute usage)
AttributeID
(Attribute ID logical format)
InstanceIDLogicalFormat
(Instance ID logical format)
ClassIDLogicalFormat
(Class ID logical format)
TRUE
_8BIT
1
