8 CIP Message Communications

8-30

NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)

Operating

CIPClose_instance.Done

Processing after normal end

1 // Processing after normal end

Inline ST

2 ;

Operating

Processing after error end.

CIPOpen_instance.Error

CIPRead_instance.Error

Inline ST

1 // Processing after error end.

2 ;

CIPWrite_instance.Error

CIPClose_instance.Error

CIPSend_instance.Error
