8 CIP Message Communications
8-54
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
03 hex Physical Address Gives the MAC address of the
interface.
Read ARRAY
[0...5] OF
USINT
Reads the current value of the
MAC address.
04 hex Interface Counters The number of packets
sent/received through the inter-
face.
Read Struct ---
In Octets The number of octets received
through the interface.
This includes unnecessary multi-
cast packets and discarded pack-
ets counted by InDiscards.
UDINT Reads the current value.
In Unicast Packets The number of unicast packets
received through the interface.
This does not include discarded
packets counted by InDiscards.
UDINT Reads the current value.
In NonUnicast Packets The number of packets besides
unicast packets received through
the interface. This includes
unnecessary multicast packets,
but does not include discarded
packets counted by InDiscards.
UDINT Reads the current value.
In Discards The number of discarded incom-
ing packets received through the
interface.
UDINT Reads the current value.
In Errors The number of incoming packets
that had errors. This is not
included in InDiscards.
UDINT Reads the current value.
In Unknown Protos The number of incoming packets
that were of an unknown protocol.
UDINT Reads the current value.
Out Octets The number of octets sent
through the interface.
UDINT Reads the current value.
Out Unicast Packets The number of unicast packets
sent through the interface.
UDINT Reads the current value.
Out NonUnicast Packets The number of packets besides
unicast packets sent through the
interface.
UDINT Reads the current value.
Out Discards The number of discarded sent
packets.
UDINT Reads the current value.
Out Errors The number of sent packets that
had errors.
UDINT Reads the current value.
Attribute ID Parameter name Description Attribute
Read/write data
Data
type
Value
