8 CIP Message Communications
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
8-7 Variable Data Types
8
8-7-3 Elementary Data Types
Applicable data types: LINT, ULINT, ULINT BCD, LREAL, and LWORD
Data Format
Data Format
* Specify 0 when writing data.
Fixed-length 8-byte Data
Boolean Data
USINT Data Type
USINT 00 hex
UINT Num of Elem (L) 01 hex
(H) 00 hex
Data
(Least-significant byte)
:
:
:
:
:
:
(Most-significant byte)
USINT Data Type C1 hex
USINT 00 hex
UINT Num of Elem (L) 01 hex
(H) 00 hex
USINT Status 01 hex: TRUE, 00 hex : FALSE
USINT
Forced set/reset information* 01 hex: Forced, 00 hex: Not forced
