5-27
5
* 1. The unit is set in o1-03 (frequency units of reference setting and monitor, default: 0.01 Hz). If the display unit is changed, the setting range values also
change
* 2. The maximum setting value depends on the setting of the maximum output frequency (E1-04).
îš„Reference Limits: d2
d1-12
Frequency
reference 12
Sets the frequency reference
when multi-step speed com-
mands 1, 2, and 4 are ON for
multi-function inputs.
0 to
FMAX
(E1-04)
*1*2
0.00 Hz Yes A A A A 28DH 6-10
Reference
12
d1-13
Frequency
reference 13
Sets the frequency reference
when multi-step speed com-
mands 3 and 4 are ON for
multi-function inputs.
0.00 Hz Yes A A A A 28EH 6-10
Reference
13
d1-14
Frequency
reference 14
Sets the frequency reference
when multi-step speed com-
mands 1, 3, and 4 are ON for
multi-function inputs.
0.00 Hz Yes A A A A 28FH 6-10
Reference
14
d1-15
Frequency
reference 15
Sets the frequency reference
when multi-step speed com-
mands 2, 3, and 4 are ON for
multi-function inputs.
0.00 Hz Yes A A A A 290H 6-10
Reference
15
d1-16
Frequency
reference 16
Sets the frequency reference
when multi-step speed com-
mands 1, 2, 3, and 4 are ON
for multi-function inputs.
0.00 Hz Yes A A A A 291H 6-10
Reference
16
d1-17
Jog fre-
quency ref-
erence
Sets the frequency reference
when the jog frequency refer-
ence selection, FJOG com-
mand, or RJOG command is
ON.
6.00 Hz Yes Q Q Q Q 292H
4-5
6-10
6-75
Jog Refer-
ence
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
V/f
with
PG
Open
Loop
Vector
Closed
Loop
Vector
Display
d2-01
Frequency
reference
upper limit
Sets the frequency reference
upper limit as a percentage of
the max. output frequency.
0.0 to
110.0
100.0% No A A A A 289H
6-32
6-71
Ref Upper
Limit
d2-02
Frequency
reference
lower limit
Sets the frequency reference
lower limit as a percentage of
the maximum output fre-
quency.
0.0 to
110.0
0.0% No A A A A 28AH
6-32
6-71
Ref Lower
Limit
d2-03
Master
speed refer-
ence lower
limit
Sets the master speed refer-
ence lower limit as a percent-
age of the max. output
frequency.
0.0 to
110.0
0.0% No A A A A 293H
6-32
6-71
Ref1 Lower
Limit
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
V/f
with
PG
Open
Loop
Vector
Closed
Loop
Vector
Display
