 Motor 2 V/f Pattern: E3
Param
eter
Num-
ber
Name
Description
Set-
ting
Range
Fac-
tory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
V/f
with
PG
Open
Loop
Vector
Closed
Loop
Vector
Display
E3-01
Motor 2
control
method
selection
0:V/f control
1:V/f control with PG
2: Open Loop Vector control
3: Closed Loop Vector Control
0 to 3 0 No A A A A 319H 6-120
Control
Method
E3-02
Motor 2
max. output
frequency
(FMAX)
To set V/f characteristics in a straight
line, set the same values for E3-05
and E3-07.
In this case, the setting for E3-06 will
be disregarded.
Always ensure that the four frequen-
cies are set in the following manner:
E3-02 (FMAX) ≥ E3-04 (FA) > E3-
05 (FB) > E3-07 (FMIN)
40.0 to
150.0
* 1
* 1. The given setting range is valid if Heavy Duty is selected (C6-01=0, default setting). If Normal Duty 1 or 2 is selected (C6-01=1 or 2) the setting range
will be 0.0 to 400.0 Hz
50.0
Hz
No A A A A 31AH 6-120
Max
Frequency
E3-03
Motor 2
max. output
voltage
(VMAX)
0.0 to
255.0
* 2
* 2. These are values for a 200 Vclass Inverter. Values for a 400 V class Inverter are double.
200.0
V
*2
No A A A A 31BH 6-120
Max
Voltage
E3-04
Motor 2
max. volt-
age fre-
quency (FA)
0.0 to
150.0
*1
50.0
Hz
No A A A A 31CH 6-120
Base
Frequency
E3-05
Motor 2
mid. output
frequency 1
(FB)
0.0 to
150.0
*1
2.5 Hz
* 3
* 3. The factory setting will change when the control method is changed. (V/f control factory settings are given.)
No A A A No 31DH 6-120
Mid
Frequency
E3-06
Motor 2
mid. output
frequency
voltage 1
(VB)
0.0 to
255.0
*2
15.0 V
*2 *3
No A A A No 31EH 6-120
Mid
Voltage
E3-07
Motor 2
min. output
frequency
(FMIN)
0.0 to
150.0
*1
1.2 Hz
*3
No A A A A 31FH 6-120
Min
Frequency
E3-08
Motor 2
min. output
frequency
voltage
(VMIN)
0.0 to
255.0
*2
9.0 V
*2 *3
No A A A No 320H 6-120
Min
Voltage
Output voltage (V)
Frequency (Hz)
