5-33
5
E2-07
Motor iron
saturation
coefficient 1
Sets the motor iron saturation
coefficient at 50% of magnetic
flux.
This parameter is automati-
cally set during rotating auto-
tuning.
0.00 to
0.50
0.50 No No No A A 314H 6-111
Saturation
Comp1
E2-08
Motor iron
saturation
coefficient 2
Sets the motor iron saturation
coefficient at 75% of magnetic
flux.
This parameter is automati-
cally set during rotating auto-
tuning.
0.50 to
0.75
0.75 No No No A A 315H 6-111
Saturation
Comp2
E2-09
Motor
mechanical
losses
Sets the motor mechanical
losses as a percentage of
motor rated output.
Usually changing this setting
is not necessary.
Adjust the value under the fol-
lowing the torque loss is large
due e.g. to heavy friction in
the machine.
The set mechanical loss will
be compensated.
0.0 to
10.0
0.0% No No No No A 316H 6-111
Mechanical
loss
E2-10
Motor iron
loss for
torque com-
pensation
Sets motor iron losses.
0 to
65535
14 W
*2
No A A No No 317H 6-111
Tcomp Iron
Loss
E2-11
Motor rated
output
power
Sets the rated output power of
the motor.
This parameter is an input data
for autotuning.
0.00 to
650.00
0.40
kW
*2
No Q Q Q Q 318H 6-111
Mtr Rated
Power
* 1. The setting range is 10% to 200% of the Inverter rated output current. The value for a 200 V class inverter of 0.4 kW is given.
* 2. The factory setting depends on the Inverter capacity. The value for a 200 V class inverter of 0.4 kW is given.
* 3. The setting range is 0.00A to (E2-01 - 0.01A).
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
V/f
with
PG
Open
Loop
Vector
Closed
Loop
Vector
Display
