5-45
5
 Multi-function Digital Outputs: H2
Multi-function Digital Output Functions
90
Follower Disable (ON: Follower mode is disabled and the drive will follow the nor-
mal frequency reference (based on b1-01 setting) and use the normal accel/decel
times.
Yes Yes Yes Yes 6-134
91 MOP Adjust Increase (ON: The MOP ratio adjustment is increased) Yes Yes Yes Yes 6-134
92 MOP Adjust Decrease (ON: The MOP ratio adjustment is decreased) Yes Yes Yes Yes 6-134
93 MOP Adjust Reset (ON: The MOP ratio adjustment is reset to 0) Yes Yes Yes Yes 6-134
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
V/f
with
PG
Open
Loop
Vector
Closed
Loop
Vector
Display
H2-01
Terminal
M1-M2
function
selection
Multi-function digital
output 1
0 to 38 0 No A A A A 40BH -
Term
M1-M2 Sel
H2-02
Terminal
M3-M4
function
selection
Multi-function digital
output 2
0 to 38 1 No A A A A 40CH -
Term
M3-M4 Sel
H2-03
Terminal
M5-M6
function
selection
Multi-function digital
output 3
0 to 38 2 No A A A A 40DH -
Term
M5-M6 Sel
Setting
Value
Function
Control Methods
Page
V/f
V/f
with
PG
Open
loop
Vector
Closed
Loop
Vector
0 During run (ON: run command is ON or voltage is being output) Yes Yes Yes Yes 6-77
1 Zero-speed Yes Yes Yes Yes 6-77
2
f
ref
= f
out
agree 1 (detection width L4-02 is used.)
Yes Yes Yes Yes 6-33
3
f
out
= f
set
agree 1 (ON: Output frequency = ±L4-01, with detection width L4-02
used and during frequency agree)
Yes Yes Yes Yes 6-33
4
Frequency detection 1 (ON: +L4-01 ≥ output frequency ≥ -L4-01, with detection
width L4-02 used)
Yes Yes Yes Yes 6-33
5
Frequency detection 2 (ON: Output frequency ≥ +L4-01 or output frequency ≤ -L4-
01, with detection width L4-02 used)
Yes Yes Yes Yes 6-33
6
Inverter operation ready
READY: After initialization or no faults
Yes Yes Yes Yes 6-78
7 During DC bus undervoltage (UV) detection Yes Yes Yes Yes 6-78
8 During baseblock (NO contact, ON: during baseblock) Yes Yes Yes Yes 6-78
9 Frequency reference source selection (ON: Frequency reference from Operator) Yes Yes Yes Yes 6-78
A Run command source selection status (ON: Run command from Operator) Yes Yes Yes Yes 6-78
B
Overtorque/undertorque detection 1 NO (NO contact, ON: Overtorque/undertorque
detection)
Yes Yes Yes Yes 6-49
C Loss of frequency reference (Effective when 1 is set for L4-05) Yes Yes Yes Yes 6-60
Setting
Value
Function
Control Methods
Page
V/f
V/f
with
PG
Open
Loop
Vector
Closed
Loop
Vector
