Omron VARISPEED F7

5-47
5
Analog Inputs: H3
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
V/f
with
PG
Open
Loop
Vector
Closed
Loop
Vector
Display
H3-01
Multi-func-
tion analog
input termi-
nal A1 sig-
nal level
selection
Sets the analog input A1 sig-
nal level.
0: 0 to +10V (11 bit)
1: –10V to +10V (11 bit plus
sign)
0 or 1 0 No A A A A 410H 6-27
Term A1
Signal
H3-02
Gain (termi-
nal A1)
Sets the frequency as a per-
centage of the maximum out-
put frequency, when 10 V is
input.
0.0 to
1000.0
100.0% Yes A A A A 411H 6-27
Terminal A1
Gain
H3-03
Bias (termi-
nal A1)
Sets the frequency as a per-
centage of the maximum fre-
quency, when 0 V is input.
-100.0
to
+100.0
0.0% Yes A A A A 412H 6-27
Terminal A1
Bias
H3-04
* 1
Signal level
selction (AI-
14B, chan-
nel 3)
Sets the signal level of AI-
14B, channel 3.
0: 0 to +10V (11 bit)
1: –10V to +10V (11 bit plus
sign)
0 or 1 0 No A A A A 413H 6-27
Term A3
Signal
H3-05
*1
Multi-func-
tion analog
input (AI-
14B, chan-
nel 3) func-
tion
selection
Selects the multi-function ana-
log input function for AI-14B,
channel 3. Refer to the table
below.
0 to 21 1F No A A A A 414H 6-27
Term A3 Sel
H3-06
*1
Gain (AI-
14B, chan-
nel 3)
Sets the input level when AI-
14B, channel input is 10 V
according to the 100% value
of the function set in parame-
ter H3-05.
0.0 to
1000.0
100.0% Yes A A A A 415H 6-27
Terminal A3
Gain
H3-07
*1
Bias (AI-
14B, chan-
nel 3)
Sets the input level when AI-
14B, channel 3 is 0 V accord-
ing to the 100% value of the
function set in parameter H3-
05.
-100.0
to
100.0
0.0% Yes A A A A 416H 6-27
Terminal A3
Bias
H3-08
Multi-func-
tion analog
input termi-
nal A2 sig-
nal level
selection
Sets the analog input A2 sig-
nal level.
0: 0 to +10V (11 bit).
1: –10V to +10V (11 bit plus
sign).
2: 4 to 20 mA (9-bit input).
Switch current and voltage
input using the switch S1 on
the control terminal board.
0 to 2 2 No A A A A 417H 6-27
Term A2
Signal
H3-09
Multi-func-
tion analog
input termi-
nal A2 func-
tion
selection
Selects the multi-function ana-
log input function for terminal
A2. Refer to the table below.
If H3-13 is set to 1, H3-09
selects the function for analog
input A1.
0 to 1F 0 No A A A A 418H 6-27
Terminal A2
Sel
