Omron VARISPEED F7 User Manual

5-50
5
MEMOBUS Communications: H5
H4-07
Analog out-
put 1 signal
level selec-
tion
Sets the signal output level for
multi-function output 1 (ter-
minal FM)
0: 0 to +10 V output
1: –10V to +10V output
2: 4 – 20 mA
Switch current and voltage
output using CN15 on the
control panel
0 to 2 0 No A A A A 423H 6-80
AO Level
Select1
H4-08
Analog out-
put 2 signal
level selec-
tion
Sets the signal output level for
multi-function output 2 (ter-
minal AM)
0: 0 to +10 V output
1: –10V to +10V output
2: 4 – 20 mA
Switch current and voltage
output using CN15 on the
control panel
0 to 2 0 No A A A A 424H 6-80
AO Level
Select2
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
V/f
with
PG
Open
Loop
Vector
Closed
Loop
Vector
Display
H5-01
Station
address
Sets the Inverter's node
address.
0 to 20
*
1F No A A A A 425H 6-83
Serial
Comm Adr
H5-02
Communica-
tions speed
selection
Sets the baud rate for MEMO-
BUS communications.
0: 1200 bps
1: 2400 bps
2: 4800 bps
3: 9600 bps
4: 19200 bps
0 to 4 3 No A A A A 426H 6-83
Serial Baud
Rate
H5-03
Communica-
tions parity
selection
Sets the parity for MEMO-
BUS communications.
0: No parity
1: Even parity
2: Odd parity
0 to 2 0 No A A A A 427H 6-83
Serial Com
Sel
H5-04
Stopping
method after
communica-
tions fault
Sets the stopping method for
communications faults.
0: Deceleration to stop using
the deceleration time in
C1-02
1: Coast to stop
2: Fast stop using the
deceleration time in C1-09
3: Continue operation
0 to 3 3 No A A A A 428H 6-83
Serial Fault
Sel
H5-05
Communica-
tions fault
detection
selection
Sets whether or not a commu-
nications time-out is to be
detected as a communications
fault.
0: Do not detect.
1: Detect
0 or 1 1 No A A A A 429H 6-83
Serial Flt
Dtct
H5-06
Send wait
time
Sets the time from the Inverter
receiving data to when the
Inverter starts to send.
5 to 65 5 ms No A A A A 42AH 6-83
Transmit
WaitTIM
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
V/f
with
PG
Open
Loop
Vector
Closed
Loop
Vector
Display
