5-69
5
T1-02
Motor out-
put power
Sets the output power of the
motor in kilowatts.
0.00 to
650.00
0.40
kW
* 2
No Yes Ye s Yes Yes 7 02 H 4-11
Mtr Rated
Power
T1-03
Motor rated
voltage
Sets the rated voltage of the
motor.
0 to
255.0
* 3
200.0 V
*3
No No No Yes Yes 703H 4-11
Rated
Voltage
T1-04
Motor rated
current
Sets the rated current of the
motor.
0.32 to
6.40
* 4
1.90 A
*2
No Yes Ye s Yes Yes 7 04 H 4-11
Rated
Current
T1-05
Motor base
frequency
Sets the base frequency of the
motor.
0 to
150.0
* 5
50.0 Hz No No No Yes Yes 705H 4-11
Rated Fre-
quency
T1-06
Number of
motor poles
Sets the number of motor
poles.
2 to 48
poles
4 poles No No No Yes Yes 706H 4-11
Number of
Poles
T1-07
Motor base
speed
Sets the base speed of the
motor in r/min.
0 to
24000
1750
r/min
No No No Yes Yes 707H 4-11
Rated Speed
T1-08
Number of
PG pulses
Sets the number of PG pulses
per revolution.
0 to
60000
1024 No No No No Yes 708H 4-11
PG Pulses/
Rev
T1-09
Motor no-
load current
Sets the current value
recorded in the motor’s test
results for a motor without a
load.
Displayed only when Non-
Rotating Auto-Tuning 2 is
selected (T1-01=4)
0.00 to
1.89
* 6
1.20 A
*2
No No No Yes Yes 709H 4-11
No-Load
Current
* 1. For V/f control V/f control with PG the setting range is limited to setting 2 only.
* 2. The factory setting depends on the Inverter capacity. (The value for a 200 V Class Inverter for 0.4 kW is given.)
* 3. These are values for a 200 V class Inverter. Values for 400 V class Inverter are double.
* 4. The setting range is from 10% to 200% of the Inverter rated output current. (The value for a 200 V Class Inverter of 0.4kW is given)
* 5. The given setting range is valid if Heavy Duty is selected (C6-01=0, default setting). If Normal Duty 1 or 2 is selected (C6-01= 1 or 2) the setting
range will be 0.0 to 400.0 Hz.
* 6. The setting range depends on the Inverter capacity. The value for a 200 V Class Inverter of 0.4kW is given.
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
V/f
with
PG
Open
Loop
Vector
Closed
Loop
Vector
Display
To Next Page
