5-74
5
U1.85
Master
encoder fre-
quency ref-
erence
Displays the frequency refer-
ence from the master drive
before gear ratios and gains
are applied.
10 V: Max. output frequency
(E1-04)
0.1
Hz
Yes Yes Yes Yes 71BH
Master PG
Fref
U1-86
Follower
frequency
reference
after gear
ratio
Displays the frequency refer-
ence from the master drive
after the gear ratio (S1-03 to
S1-06) has been applied.
10V: Max. output frequency
(E1-04)
0.1
Hz
Yes Yes Yes Yes 72CH
FrefAfter
Gear
U1-87
Gear ratio
adjustment
Displays the total gear ratio
adjustment (sum of digital,
analog, MOP and communi-
cation adjustments)
10V: 100.00%
0.01
%
Yes Yes Yes Yes 71DH
Gear Ratio
Adj
U1-88
Follower
reference
after gear
ratio adjust-
ment
Displays the frequency refer-
ence from the master drive
after the digital, analog, MOP
and communication gear
ration adjustments have been
applied.
10V: Maximum frequency
(E1-04)
0.1
Hz
Yes Yes Yes Yes 71EH
Fref After
Adj
* 1. This monitor parameter is only visible when the AI-14B (Analogue input) option card is conneccted and F2-01=0.
Param-
eter
Num-
ber
Name
Description
Output Signal Level During
Multi-Function Analog Output
Min.
Unit
Control Methods
MEMO-
BUS
Register
V/f
V/f
with
PG
Open
Loop
Vector
Closed
Loop
Vector
Display
