Omron VARISPEED F7 User Manual

6-100
6
Related Parameters
Monitor Items (U1-)
Parameter
No.
Name
Factory
Setting
Change
during
Opera-
tion
Control Methods
V/f
V/f with
PG
Open
Loop
Vector
Closed
Loop
Vector
b5-01 PID control mode selection 0 No A A A A
b5-02 Proportional gain (P) 1.00 Yes A A A A
b5-03 Integral (I) time 1.0 s Yes A A A A
b5-04 Integral (I) limit 100.0% Yes A A A A
b5-05 Differential (D) time 0.00 s Yes A A A A
b5-06 PID limit 100.0% Yes A A A A
b5-07 PID offset adjustment 0.0% Yes A A A A
b5-08 PID delay time constant 0.00 s Yes A A A A
b5-09 PID output characteristics selection 0 No A A A A
b5-10 PID output gain 1.0 No A A A A
b5-11 PID reverse output selection 0 No A A A A
b5-12 Selection of PID feedback loss detection 0 No A A A A
b5-13 PID feedback loss detection level 0% No A A A A
b5-14 PID feedback loss detection time 1.0 s No A A A A
b5-15 PID sleep function operation level 0.0 Hz No A A A A
b5-16 PID sleep operation delay time 0.0 s No A A A A
b5-17 Accel/decel time for PID reference 0.0 s No A A A A
b5-18 PID Setpoint Selection 0 No A A A A
b5-19 PID set point 0 No A A A A
b5-28 PID square root feedback selection 0 No A A A A
b5-29 Square root feedback gain 1.00 No A A A A
b5-31 PID monitor feedback selection 0 No A A A A
b5-32 PID monitor feedback gain 100.0% No A A A A
b5-33 PID monitor feedback bias 0.0% No A A A A
Parameter
Number
Name
Output Signal Level During
Multi-Function Analog Output
Min.
Unit
Control Methods
V/f
V/f
with
PG
Open
Loop
Vector
Closed
Loop
Vector
U1-24 PID feedback value 10 V: 100% feedback 0.01% A A A A
U1-36 PID input volume 10 V: 100% PID input 0.01% A A A A
U1-37 PID output volume 10 V: 100% PID output 0.01% A A A A
U1-38 PID set point 10 V: 100% PID target 0.01% A A A A
