6-101
6
Multi-Function Digital Inputs (H1-01 to H1-05)
Multi-Function Analog Input (H3-09)
Pulse Train Input (H6-01)
îš„PID Control Methods (b5-01)
There are four PID control methods. Select the method by setting parameter b5-01.
Set
Value
Function
Control Methods
V/f
V/f
with
PG
Open
loop
Vector
Closed
Loop
Vector
19 PID control disable (ON: PID control disabled) Yes Yes Yes Yes
30 PID control integral reset (reset when reset command is input or when stopped during PID control) Yes Yes Yes Yes
31 PID control integral hold (ON: Integral hold) Yes Yes Yes Yes
34 PID soft starter Yes Ye s Yes Ye s
35 PID input characteristics switch Yes Yes Yes Yes
Set
Value
Function
Control Methods
V/f
V/f
with
PG
Open
loop
Vector
Closed
Loop
Vector
B PID feedback Yes Ye s Yes Ye s
C PID target value Yes Ye s Yes Ye s
Set
Value
Function
Control Methods
V/f
V/f
with
PG
Open
Loop
Vector
Closed
Loop
Vector
0 Frequency reference Yes Ye s Yes Ye s
1 PID feedback value Ye s Ye s Yes Yes
2 PID target value Ye s Yes Ye s Ye s
Set Value Control Method
1
PID output becomes the Inverter output frequency, and D control is used in the deviation (difference between PID target value and
feedback value.)
2 PID output becomes the Inverter output frequency, and D control is used in the PID feedback value.
3
PID output is added as compensation value of the Inverter output frequency, and D control is used in the deviation (difference
between PID target value and feedback value).
4 PID output is added as compensation value of the Inverter output frequency, and D control is used in the PID feedback value.
