Storing Inverter set values in the Digital Operator (READ)
To store Inverter set values in the Digital Operator use the following method.
If a fault is displayed, press any key to cancel the fault display and return to the o3-01 display. Refer to
page 7-18, Digital Operator Copy Function Faults for corrective actions.
Step
No.
Explanation Digital Operator Display
1 Press the Menu Key and select advanced programming mode.
2 Press the DATA/ENTER Key.
3
Press the Increment and Decrement Key until parameter o3-01 is displayed
(Copy Function Selection).
4 Press the DATA/ENTER Key and select the constants setting display.
5 Change the set value to 1 using the Increment Key.
6
Set the changed data using the DATA/ENTER Key. The READ function will
start.
7
If the READ function ends normally, “End” is displayed on the Digital Oper-
ator.
8 The display returns to o3-01 when a key is pressed.
** Main Menu **
-ADV-
Programming
Initialization
-ADV-
A1 - 00=1
Select Language
COPY Function
-ADV-
o3 - 01=0
Copy Funtion Sel
Copy Function Sel
-ADV-
o3
-01= 0
COPY SELECT
*0*
Copy Function Sel
-ADV-
o3
-01=
1
*0*
INV OP READ
READ
-ADV-
INV OP
READING
READ
-ADV-
READ COMPLETE
Copy Function Sel
-ADV-
o3
-
01=0
COPY SELECT
*0*
