d4-02 + - Speed limits 10%
d5-01 Torque control selection 0
d5-02 Torque reference delay time 0 ms
d5-03 Speed limit selection 1
d5-04 Speed limit 0%
d5-05 Speed limit bias 10%
d5-06 Speed/torque control switching timer 0 ms
d6-01 Field weakening level 80%
d6-02 Field weakening frequency limit 0.0 Hz
d6-03 Field forcing function selection 0
d6-06 Field forcing function Limit 400%
E1-01 Input voltage setting *1
E1-03 V/f pattern selection F
E1-04 Max. output frequency (FMAX) 50.0 Hz
E1-05 Max. output voltage (VMAX) *1
E1-06 Base frequency (FA) 50.0 Hz
E1-07 Mid. output frequency (FB) *1
E1-08 Mid. output frequency voltage (VB) *1
E1-09 Min. output frequency (FMIN) *1
E1-10 Min. output frequency voltage (VMIN) *1
E1-11 Mid. output frequency 2 0.0 Hz
E1-12 Mid. output frequency voltage 2 0.0 V
E1-13 Base voltage (VBASE) 0.0 V
E2-01 Motor rated current *1
E2-02 Motor rated slip *1
E2-03 Motor no-load current *1
E2-04 Number of motor poles 4 poles
E2-05 Motor line-to-line resistance *1
E2-06 Motor leak inductance *1
E2-07 Motor iron saturation coefficient 1 0.50
E2-08 Motor iron saturation coefficient 2 0.75
E2-09 Monitor mechanical losses 0.0%
E2-10 Motor iron loss for torque compensation *1
E2-11 Motor rated output power *1
E3-01 Motor 2 control method selection 0
E3-02 Motor 2 max. output frequency (FMAX) 50.0 Hz
E3-03 Motor 2 max. output voltage (VMAX) *1
E3-04 Motor 2 max. output voltage frequency (FA) 50.0 Hz
E3-05 Motor 2 mid. output frequency 1 (FB) *1
E3-06 Motor 2 mid. output frequency voltage 1 (VB) *1
E3-07 Motor 2 min. output frequency (FMIN) *1
E3-08 Motor 2 min. output frequency voltage (VMIN) *1
E4-01 Motor 2 rated current *1
E4-02 Motor 2 rated slip *1
E4-03 Motor 2 no-load current *1
No. Name
Factory
Setting
Setting
