10-11
10
E4-04 Motor 2 number of poles (number of poles) 4 poles
E4-05 Motor 2 line-to-line resistance *1
E4-06 Motor 2 leak inductance *1
E4-07 Motor 2 rated capacity *1
F1-01 PG constant 1024
F1-02 Operation selection at PG open circuit (PGO) 1
F1-03 Operation selection at overspeed (OS) 1
F1-04 Operation selection at deviation 3
F1-05 PG rotation 0
F1-06 PG division rate (PG pulse monitor) 1
F1-07 Integral value during accel/decel enable/disable 0
F1-08 Overspeed detection level 115%
F1-09 Overspeed detection delay time 1.0 s
F1-10 Excessive speed deviation detection level 10%
F1-11 Excessive speed deviation detection delay time 0.5 s
F1-12 Number of PG gear teeth 1 0
F1-13 Number of PG gear teeth 2 0
F1-14 PG open-circuit detection delay time 2.0 s
F2-01 Bi-polar or uni-polar input selection 0
F3-01 Digital input option 0
F4-01 Channel 1 Monitor Selection 2
F4-02 Channel 1 Gain 100.0%
F4-03 Channel 2 Monitor Selection 3
F4-04 Channel 2 Gain 50.0%
F4-05 CH1 Output Bias 0.0%
F4-06 CH2 Output Bias 0.0%
F4-07 Analog Output Signal Level CH1 0
F4-08 Analog Output Signal Level CH2 0
F5-01 Channel 1 Output Selection 0
F5-02 Channel 2 Output Selection 1
F5-03 Channel 3 Output Selection 2
F5-04 Channel 4 Output Selection 4
F5-05 Channel 5 Output Selection 6
F5-06 Channel 6 Output Selection 37
F5-07 Channel 7 Output Selection 0F
F5-08 Channel 8 Output Selection 0F
F5-09 DO-08 Output Mode Selection 0
F6-01 Operation selection after communications fault 1
F6-02 Input level of external fault from Communications Option Card 0
F6-03 Stopping method for external fault from Communications Option Card 1
F6-04 Trace sampling from Communications Option Card 0
F6-05 Current monitor unit selection 1
F6-06 Torque reference/torque limit selection from communications option card 1
F6-08 Operation selection after SI-T WDT error 1
F6-09 Number of SI-T BUS error detection 2
No. Name
Factory
Setting
Setting
