10-12
10
H1-01 Terminal S3 function selection 24
H1-02 Terminal S4 function selection 14
H1-03 Terminal S5 function selection
3 (0)
*2
H1-04 Terminal S6 function selection
4 (3)
*2
H1-05 Terminal S7 function selection
6 (4)
*2
H2-01 Terminal M1-M2 function selection 0
H2-02 Terminal M3-M4 function selection 1
H2-03 Terminal M5-M6 function selection 2
H3-01 Multi-function analog input terminal A1 signal level selection 0
H3-02 Gain (terminal A1) 100.0%
H3-03 Bias (terminal A1) 0.0%
H3-04 Signal level selction (AI-14B, channel 3) 0
H3-05 Multi-function analog input (AI-14B, channel 3) function selection 1F
H3-06 Gain (AI-14B, channel 3) 100.0%
H3-07 Bias (AI-14B, channel 3) 0.0%
H3-08 Multi-function analog input terminal A2 signal level selection 2
H3-09 Multi-function analog input terminal A2 function selection 0
H3-10 Gain (terminal A2) 100.0%
H3-11 Bias (terminal A2) 0.0%
H3-12 Analog input filter time constant 0.00 s
H3-13 Terminal A1/A2 switching 0
H4-01 Monitor selection (terminal FM) 2
H4-02 Gain (terminal FM) 100%
H4-03 Bias (terminal FM) 0.0%
H4-04 Monitor selection (terminal AM) 3
H4-05 Gain (terminal AM) 50.0%
H4-06 Bias (terminal AM) 0.0%
H4-07 Analog output 1 signal level selection 0
H4-08 Analog output 2 signal level selection 0
H5-01 Station address 1F
H5-02 Communications speed selection 3
H5-03 Communications parity selection 0
H5-04 Stopping method after communications fault 3
H5-05 Communications fault detection selection 1
H5-06 Send wait time 5 ms
H5-07 RTS control ON/OFF 1
H5-10 Unit Selection for MEMOBUS register 0025H 0
H6-01 Pulse train input function selection 0
H6-02 Pulse train input scaling 1440 Hz
H6-03 Pulse train input gain 100.0%
H6-04 Pulse train input bias 0.0%
H6-05 Pulse train input filter time 0.10 s
H6-06 Pulse train monitor selection 2
H6-07 Pulse train monitor scaling 1440 Hz
No. Name
Factory
Setting
Setting
