10-13
10
L1-01 Motor protection selection 1
L1-02 Motor protection time constant 1.0 min
L1-03 Alarm operation selection during motor overheating 3
L1-04 Motor overheating operation selection 1
L1-05 Motor temperature input filter time constant 0.20 s
L2-01 Momentary power loss detection 0
L2-02 Momentary power loss ride through time *1
L2-03 Min. baseblock time *1
L2-04 Voltage recovery time *1
L2-05 Undervoltage detection level *1
L2-06 KEB deceleration time 0.0 s
L2-07 Momentary recovery time *1
L2-08 Frequency reduction gain at KEB start 100%
L3-01 Stall prevention selection during accel 1
L3-02 Stall prevention level during accel 150%
L3-03 Stall prevention limit during accel 50%
L3-04 Stall prevention selection during decel 1
L3-05 Stall prevention selection during running 1
L3-06 Stall prevention level during run 150%
L4-01 Speed agreement detection level 0.0 Hz
L4-02 Speed agreement detection width 2.0 Hz
L4-03 Speed agreement detection level (+/-) 0.0 Hz
L4-04 Speed agreement detection width (+/-) 2.0 Hz
L4-05 Operation when frequency reference is missing 0
L4-06 Frequency reference value at frequency reference loss 80%
L4-12 Width of frequency reference loss 10%
L5-01 Number of auto restart attempts 0
L5-02 Auto restart operation selection 0
L6-01 Torque detection selection 1 0
L6-02 Torque detection level 1 150%
L6-03 Torque detection time 1 0.1 s
L6-04 Torque detection selection 2 0
L6-05 Torque detection level 2 150%
L6-06 Torque detection time 2 0.1 s
L7-01 Forward drive torque limit 200%
L7-02 Reverse drive torque limit 200%
L7-03 Forward regenerative torque limit 200%
L7-04 Reverse regenerative torque limit 200%
L7-06 Torque limit time constant 200 ms
L7-07 Torque Limit Operation during accel/decel 0
L8-01 Protect selection for internal DB resistor (Type ERF) 0
L8-02 Overheat pre-alarm level
95 °C
*1
L8-03 Operation selection after overheat pre-alarm 3
L8-05 Input open-phase protection selection 1
L8-07 Output open-phase protection selection 0
No. Name
Factory
Setting
Setting
