L8-09 Ground protection selection 1
L8-10 Cooling fan control selection 0
L8-11 Cooling fan control delay time 60 s
L8-12 Ambient temperature 45 °C
L8-15 OL2 characteristics selection at low speeds 1
L8-18 Soft CLA selection 1
L8-32 OH1 detection of Inverter’s cooling fan 1
n1-01 Hunting-prevention function selection 1
n1-02 Hunting-prevention gain 1.00
n2-01 Speed feedback detection control (AFR) gain 1.00
n2-02 Speed feedback detection control (AFR) time constant 50 ms
n2-03 Speed feedback detection control (AFR) time constant 2 750 ms
n3-01 High-slip braking deceleration frequency width 5%
n3-02 High-slip braking current limit 150%
n3-03 High-slip braking stop dwell time 1.0 s
n3-04 High-slip braking OL time 40 s
o1-01 Monitor selection 6
o1-02 Monitor selection after power up 1
o1-03 Frequency units of reference setting and monitor 0
o1-04 Setting unit for frequency parameters related to V/f characteristics 0
o1-05 LCD Display contrast adjustment 3
o2-01 LOCAL/REMOTE key enable/disable 1
o2-02 STOP key during control circuit terminal operation 1
o2-03 User parameter initial value 0
o2-04 kVA selection 0
o2-05 Frequency reference setting method selection 0
o2-06 Operation selection when digital operator is disconnected 0
o2-07 Cumulative operation time setting 0 hr
o2-08 Cumulative operation time selection 0
o2-09 Initialize Mode 2
o2-10 Fan operation time setting 0 hr
o2-12 Fault trace initialize 0
o2-14 kWh monitor initialize 0
o3-01 Copy function selection 0
o3-02 Read permission selection 0
S1-01 Follower Mode Selection 0
S1-02 Master encoder PPR 1024
S1-03 Ratio Numerator (Upper 4 digits) 1000
S1-04 Ratio Numerator (Upper 4 Digits) 1000
S1-05 Ratio Numerator (Lower 4 Digits) 0
S1-06 Ratio Denominator (Lower 4 Digits) 0
S2-01 Digital Ratio Adjustments 0.00 %
S2-02 MOP Adjust Time 50.0 s
S2-03 Gear Ratio Adjustment Ramp Time 10.0 s
S2-04 PG Monitor Channel Selection 1
No. Name
Factory
Setting
Setting
