Omron VARISPEED F7 User Manual

2-9
2
F7Z4045
R/L1, S/L2, T/L3, , 1, U/T1, V/T2, W/
T3, R1/L11, S1/L21, T1/L31
M8 9.0 to 10.0
35 to 50
(2 to 1/0)
35
(2)
Power cables,
e.g., 600 V vinyl
power cables
3
M6 4.0 to 5.0
10 to 16
(8 to 4)
-
M8 9.0 to 10.0
25 to 35
(4 to 2)
25
(4)
F7Z4055
R/L1, S/L2, T/L3, , 1, U/T1, V/T2,
W/T3, R1/L11, S1/L21, T1/L31
M8 9.0 to 10.0
50
(1 to 1/0)
50
(1)
3
M6 4.0 to 5.0
10 to 16
(8 to 4)
-
M8 9.0 to 10.0
25 to 35
(4 to 2)
25
(4)
F7Z4075
R/L1, S/L2, T/L3, , 1
M10 31.4 to 39.2
70 to 95
(2/0 to 4/0)
70
(2/0)
U/T1, V/T2, W/T3, R1/L11, S1/L21, T1/L31 M10 17.6 to 22.5
50 to 100
(1/0 to 4/0)
50
(1/0)
3
M8 8.8 to 10.8
6 to 16
(10 to 4)
-
M10 31.4 to 39.2
35 to 70
(2 to 2/0)
35
(2)
r/l1, Δ200/
l2
200, Δ400/
l2
400
M4 1.3 to 1.4
0.5 to 4
(20 to 10)
1.5
(16)
F7Z4090
R/L1, S/L2, T/L3, , 1
M10 31.4 to 39.2
95
(3/0 to 4/0)
95
(4/0)
U/T1, V/T2, W/T3, R1/L11, S1/L21, T1/L31 M10 17.6 to 22.5
95
(3/0 to 4/0)
95
(4/0)
3
M8 8.8 to 10.8
10 to 16
(8 to 4)
-
M10 31.4 to 39.2
50 to 95
(1 to 4/0)
50
(1)
r/l1, Δ200/
l2
200, Δ400/
l2
400
M4 1.3 to 1.4
0.5 to 4
(20 to 10)
1.5
(16)
F7Z4110
R/L1, S/L2, T/L3, , 1
M10 31.4 to 39.2
50 to 95
(1/0 to 4/0)
50 × 2P
(1/0 × 2P)
U/T1, V/T2, W/T3, R1/L11, S1/L21, T1/L31
3
M8 8.8 to 10.8
10 to 70
(8 to 2/0)
-
M12 31.4 to 39.2
70 to 150
(2/0 to 300)
70
(2/0)
r/l1, Δ200/
l2
200, Δ400/
l2
400
M4 1.3 to 1.4
0.5 to 4
(20 to 10)
1.5
(16)
F7Z4132
R/L1, S/L2, T/L3, , 1
M10 31.4 to 39.2
95
(3/0 to 4/0)
95 × 2P
(3/0 × 2P)
U/T1, V/T2, W/T3, R1/L11, S1/L21, T1/L31
75 to 95
(2/0 to 4/0)
75 × 2P
(2/0 × 2P)
3
M8 8.8 to 10.8
10 to 70
(8 to 2/0)
-
M12 31.4 to 39.2
95 to 150
(4/0 to 300)
95
(4/0)
r/l1, Δ200/
l2
200, Δ400/
l2
400
M4 1.3 to 1.4
0.5 to 4
(20 to 10)
1.5
(16)
F7Z4160
R/L1, S/L2, T/L3, , 1
M12 31.4 to 39.2
95 to 185
(4/0 to 400)
95 × 2P
(4/0 × 2P)
U/T1, V/T2, W/T3, R1/L11, S1/L21, T1/L31
95 to 185
(3/0 to 400)
95 × 2P
(3/0 × 2P)
3
M8 8.8 to 10.8
10 to 70
(8 to 2/0)
-
M12 31.4 to 39.2
50 to 150
(1/0 to 300)
50 × 2P
(1/0 × 2P)
r/l1, Δ200/
l2
200, Δ400/
l2
400
M4 1.3 to 1.4
0.5 to 4
(20 to 10)
1.5
(16)
Table 2.2 400 V Class Wire Sizes
Inverter
Model
CIMR-
Terminal Symbol
Termi-
nal
Screws
Tightening
Torque
(N•m)
Possible
Wire Sizes
mm
2
(AWG)
Recom-
mended Wire
Size mm
2
(AWG)
Wire Type
