enter job notes for your case, change settings, and start the job. Tap the left arrow in
the job setup tab to navigate back to the previous screen or to the Home screen.
Across the top navigation bar there are buttons to quickly access the side navigation
menu , the Home screen, and view the current time. The TX1 model name in the
top navigation bar links to the Home screen.
Note: In the event of abnormal cooling conditions, a warning triangle will be
shown in the top navigation bar, to the right of the time. Such a warning will
never be seen under normal operating conditions. Please refer to
“Troubleshooting common problems” on page 204 for more information.
There are two tabs on the main screen: Home and Jobs. The Home tab shows the
Home screen or one of the many other screens. The Jobs tab always shows the Jobs
summary screen and the current number of total active and queued jobs.
The three buttons at the bottom of the Home screen are for Sources, Accessory
drives, and Destinations. The number in each area represents the number of
attached and detected drives (including mounted network shares). In addition to
providing the drive count, these buttons can be tapped to display a summary list of
available drives and allow access to further drive details, screens, and operations.
Note: The middle area of the bottom row of the Home screen (for USB Accessory
drives) is only shown when a USB Accessory drive is connected.
2.2.2 Side navigation menu
The menu icon in the upper left corner of the top navigation bar displays the side
navigation panel that provides a menu of additional options and information. For
additional information on the items in this menu, see “Configuring TX1”
on page 23.
