Once the desired filter parameters are set, simply close the Filter Logs window to
see the list of logs that match your chosen parameters. The number of logs that
matched your filter parameters is shown next to the filter icon in the bottom of the
log list window. This subset of logs can be viewed on the unit, exported to external
media, or deleted. To export or delete the filtered log list, simply tap the appropriate
button on the bottom right of the log list screen and follow the prompts. As with the
full log list, when deleting a filtered list of logs, only logs for previously completed
(inactive) jobs will be deleted.
To remove all filtering and see the entire log list again, either navigate away from
the filtered log list and then reselect the main log list, or tap the filter icon again and
then tap Clear All at the bottom right of the Filter Logs screen and close that screen.
4.12 Remote web interface
TX1 offers the ability to use any network connected TX1 unit remotely via a web
browser. If your TX1 has a user setup with remote access privileges and a valid IP
address, remote access is as simple as opening a browser window and entering the
IP address or hostname of TX1 into the address field. A login screen will always
appear first on the remote browser, and, after credentials are entered and validated,
the TX1 user interface will appear and be fully usable as if you were working locally
on the unit itself. Note that local and remote users can work independently on the
same TX1 unit. However, TX1's resources are shared between all logged in users, so
jobs and other changes made from one connection type (local or remote) will be seen
by all users and will affect what other users can do.
The remote web interface can be used to perform nearly all functions available on
the local user interface, with the following differences:
• For security reasons, the remote login screen requires typing in both the
username and password. On the local unit, a pulldown list of available
usernames is provided. Usernames and passwords are case sensitive.
• When using the Browse function remotely, any individual file from any mounted
drive with a supported filesystem can be downloaded to the remote device. After
selecting the desired file in the remote Browse window, simply tap the
Download button at the bottom right, and the file will be downloaded to your
remote system. This is a convenient way to view any file from a TX1-mounted
drive using the remote computer's applications, which can help with evidence
triage decisions.
• When accessing logs from the remote web interface, you can download targeted
log files. Select a log from the Log Details view, click the options icon
and
select Download. The Download button is not displayed when accessing TX1
locally.
• The time shown in the top-right corner of the remote view represents the time
zone of the remote computer/browser, not the time zone of TX1. However, the
logs for any remotely initiated jobs will reflect the time zone as set on TX1.
• The Factory Reset feature is not available to remote users.
Chapter 4 Using TX1
190
OpenText™ Tableau™ Forensic TX1 Imager
ISTX240300-UGD-EN-1
