Specifications and troubleshooting
6.1 Specifications
Connectors: Source Side
SATA/SAS Two SATA/SAS (6 GBPS) signal connectors
USB One USB 3.1 Gen 1 (5 GBPS) Standard-A connector
FireWire One 1394b “FireWire 800” signal connector
PCIe One PCIe (10 GBPS) adapter connector
Drive Power Two 3M-style 4-pin power connectors for SATA/SAS drive
power
Connectors: Destination Side
SATA/SAS Two SATA/SAS (6 GBPS) signal connectors
USB One USB 3.1 Gen 1 (5 GBPS) Standard-A connector
TX1-S1 One TX1-S1 (Two SATA/SAS 6 GBPS) signal connector
Drive Power Two 3M-style 4-pin power connectors for SATA/SAS drive
power
Connectors: Miscellaneous
Ethernet One 10 Gbps Ethernet Connection (Source or Destination);
auto-negotiable to 1Gbps
USB Two USB 3.1 Gen 1 (5 Gbps) Standard-A Connectors
SD Card One SD Card Connector for Device Firmware
DC Input One Barrel Connector for use with Tableau TP6 Power
Supply
User Interface
LCD 7.0 in. graphic LCD (600 x 1024 Resolution) with capacitive
touch-screen
Power Button One On/Off power button
Indicators
Power Indicator White LED indicates TX1 is powered on
Status Indicator Multi-color LED indicates TX1 job status
Speaker Audio tones indicate job completion and errors
Physical / Environment
