Oracle Database Appliance X6-2-HA Service Manual

Remove Boot Disk Backplane Cables
■
“Remove Boot Disk Backplane Cables” on page 238
■
“Install Boot Disk Backplane Cables” on page 239
Remove Boot Disk Backplane Cables
Note - Information in this appendix does NOT apply to Oracle Database Appliance X3-
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
This section describes removing the boot disk backplane cables from Oracle Database
Appliance Version 1.
1.
Prepare the server node for service.
a.
Attach an antistatic wrist strap.
See “Performing Electrostatic Discharge and Antistatic Prevention
Measures” on page 146.
b.
Remove the server node from the system.
Power is removed from the server node when you remove it from the system. See
“Removing Server Nodes From the System Chassis” on page 147.
c.
Remove the server node top cover.
See “Removing the Server Node Top Cover” on page 149.
2.
Disconnect the power cable and hard disk drive (HDD) cables and remove them
from the server node.
a.
Disconnect the power cable and HDD cables from the motherboard [1].
238 Oracle Database Appliance Service Manual • November 2017
