Remove Replaceable Components From Motherboard Assembly
■
“Install Replaceable Components in Motherboard Assembly” on page 243
Remove Replaceable Components From Motherboard
Assembly
Note - Information in this appendix does NOT apply to Oracle Database Appliance X3-
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
This section describes removing the replaceable components prior to removing the motherboard
from Oracle Database Appliance Version 1.
1.
Prepare the server node for service.
a.
Attach an antistatic wrist strap.
See “Performing Electrostatic Discharge and Antistatic Prevention
Measures” on page 146.
b.
Remove the server node from the system.
Power is removed from the server node when you remove it from the system. See
“Removing Server Nodes From the System Chassis” on page 147.
c.
Remove the server node top cover.
See “Removing the Server Node Top Cover” on page 149.
2.
With the exception the SAS expander cable, disconnect and remove all internal
cables from the server node.
Note - To identify the SAS expander cable, see “Install SAS Expander Cable” on page 236.
The cables for the fans, the primary and secondary HBA PCIe cards, and the boot disk
backplane must be removed.
■
Fan power cables
See Remove “Remove Fan Power Cables” on page 228.
■
Primary HBA PCIe card data cables
See “Remove PCIe Card Cables From Primary HBA PCIe Card” on page 230.
■
Secondary HBA PCIe card data cables
242 Oracle Database Appliance Service Manual • November 2017
