Install Replaceable Components in Motherboard Assembly
See “Remove PCIe Card Cables From Secondary HBA PCIe Card” on page 232.
Caution - Equipment damage. The HBA data cables are delicate. Ensure that they are
removed and safely out of the way when servicing the motherboard.
■
Boot disk board cables.
See “Remove Boot Disk Backplane Cables” on page 238.
3.
Remove the following components from the server node.
■
Fan modules
“Remove a Fan Module” on page 160.
■
Boot disk drives
“Remove a Boot Drive” on page 157.
■
Boot disk drive backplane
“Remove Boot Disk Backplane” on page 205.
■
Memory modules (DIMMS)
“Remove Faulty DIMMs” on page 170.
■
PCIe riser and attached PCIe cards
“Remove PCIe Riser From Server Nodes” on page 178.
■
CPUs
“Remove Processor (CPU)” on page 197.
■
Internal primary HBA PCIe card
“Remove Primary HBA PCIe Card From Motherboard” on page 187.
■
Battery
“Remove Battery” on page 191.
Install Replaceable Components in Motherboard Assembly
Note - Information in this appendix does NOT apply to Oracle Database Appliance X3-
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
This section describes reinstalling the replaceable components removed when replacing the
motherboard in Oracle Database Appliance Version 1.
Appendix A • Servicing the Oracle Database Appliance Version 1 243
