Oracle DE2-24 Customer Service Manual

Servicing the 7x20 Controller
Slot Mfg Part Number Description Max Note
2 375-3606-03 CX1 InfiniBand
HCA
4 Optional
recommended front-
end
2 7051223 2-port optical 10GE
NIC
6 Optional
recommended front-
end
2 375-3696-01 CX2 InfiniBand
HCA
4 Optional
recommended front-
end
3 F375-3609-03
(7059331 for EU
countries)
2-port SAS external
HBA
6 Additional optional
back-end
3 7054739 4-port copper NIC 6 Optional
recommended front-
end
3 371-4325-02 8Gb 2-port FC HBA 6 Optional FC target or
initiator (Backup)
3 375-3606-03 CX1 InfiniBand
HCA
4 Optional
recommended front-
end
3 7051223 2-port optical 10GE
NIC
6 Optional
recommended front-
end
3 375-3696-01 CX2 InfiniBand
HCA
4 Optional
recommended front-
end
4 7054739 4-port copper NIC 6 Optional
recommended front-
end
4 375-3606-03 CX1 InfiniBand
HCA
4 Optional
recommended front-
end
4 7051223 2-port optical 10GE
NIC
6 Optional
recommended front-
end
4 371-4325-02 8Gb 2-port FC HBA 6 Optional FC target or
initiator (Backup)
4 375-3696-01 CX2 InfiniBand
HCA
4 Optional
recommended front-
end
C 7056175 Cluster Controller
200
1 Cluster base
configuration
5 7054739 4-port copper NIC 6 Optional
recommended front-
end
Servicing the Hardware 167
