Oracle DE2-24 Customer Service Manual

Servicing the 7x20 Controller
Slot Mfg Part Number Description Max Note
5 375-3606-03 CX1 InfiniBand
HCA
4 Optional
recommended front-
end
5 7051223 2-port optical 10GE
NIC
6 Optional
recommended front-
end
5 371-4325-02 8Gb 2-port FC HBA 6 Optional FC target or
initiator (Backup)
5 375-3696-01 CX2 InfiniBand
HCA
4 Optional
recommended front-
end
6 F375-3609-03
(7059331 for EU
countries)
2-port SAS external
HBA
6 Additional optional
back-end
6 7054739 4-port copper NIC 6 Optional
recommended front-
end
6 371-4325-02 8Gb 2-port FC HBA 6 Optional FC target or
initiator (Backup)
6 375-3606-03 CX1 InfiniBand
HCA
4 Optional
recommended front-
end
6 7051223 2-port optical 10GE
NIC
6 Optional
recommended front-
end
6 375-3696-01 CX2 InfiniBand
HCA
4 Optional
recommended front-
end
7 F375-3609-03
(7059331 for EU
countries)
DP SAS external
HBA
6 Additional optional
back-end
7 7054739 4-port copper NIC 6 Optional
recommended front-
end
7 371-4325-02 8Gb 2-port FC HBA 6 Optional FC target or
initiator (Backup)
7 375-3606-03 CX1 InfiniBand
HCA
4 Optional
recommended front-
end
7 7051223 2-port optical 10GE
NIC
6 Optional
recommended front-
end
7 375-3696-01 CX2 InfiniBand
HCA
4 Optional
recommended front-
end
168 Oracle ZFS Storage Appliance Customer Service Manual • February 2016
