Servicing the eUSB Drive
The eUSB drive is mounted on the motherboard beneath memory risers CM0/MR0, CM0/MR2,
and CM0/MR3. See “Front Panel Components (Service)” on page 13.
These topics describe how to service the eUSB drive.
■
“Install the eUSB Drive” on page 116
■
“Remove the eUSB Drive” on page 115
Related Information
■
“Detecting and Managing Faults” on page 27
Remove the eUSB Drive
This is a cold-service procedure that can be performed by a customer. Power down the server
completely before performing this procedure.
Caution - This procedure requires that you handle components that are sensitive to electrostatic
discharge. Static discharges can cause the components to fail.
1.
Prepare the system for service.
See “Preparing for Service” on page 45.
2.
Remove memory risers CM0/MR0, CM0/MR2 and CM0/MR3. The eUSB drive is
located under CM0/MR2.
Servicing the eUSB Drive 115
