Interpreting LEDs
Component Oracle ILOM Target Service Procedure
PCIe card
/SYS/MB/PCIE1
/SYS/MB/PCIE2
/SYS/MB/PCIE3
/SYS/MB/PCIE4
/SYS/MB/PCIE5
/SYS/MB/PCIE6
/SYS/MB/PCIE7
/SYS/MB/PCIE8
“Servicing PCIe
Cards” on page 119
Power supplies
/SYS/PS0 (outer)
/SYS/PS1 (inner)
“Servicing Power
Supplies” on page 83
PS backplane and cover
/SYS/PDB
“Servicing the PS
Backplane” on page 165
SP
/SYS/MB/SPM
“Servicing the SPM” on page 129
Related Information
■
“Log In to Oracle ILOM (Service)” on page 28
■
“Identify Faulted Components” on page 29
■
“Identify Disabled Components” on page 31
Interpreting LEDs
Use these steps to determine if an LED indicates that a component has failed.
Step Description Links
1. Check the LEDs on the front and rear of the server. ■ “Front Panel Controls and
LEDs” on page 34
■ “Rear Panel Controls and
LEDs” on page 36
2. Check the LEDs on the individual components.
Component LEDs might not be lit even though the
component is faulty. Rely on software to determine
■ “Servicing Drives” on page 63
■ “Servicing Fan Modules” on page 75
■ “Servicing Power Supplies” on page 83
■ “Servicing Memory Risers and
DIMMs” on page 89
Detecting and Managing Faults 33
