Install a Memory Riser

■

“Remove a DIMM” on page 100

■

“Enable and Verify a DIMM” on page 106

Install a Memory Riser

Note - Your server might include a memory riser that is secured with a flat-head screw. If that is

the case, use a No. 1 flat-blade screwdriver to service that memory riser.

Take the necessary ESD precautions.

See “Prevent ESD Damage” on page 55.

104 SPARC T8-2 Server Service Manual • June 2019
