Servicing PCIe Cards
These topics describe how to service PCIe cards and PCIe card fillers.
■
“PCIe Card Configuration” on page 119
■
“NVMe Card Configuration” on page 120
■
“I/O Root Complex Connections” on page 121
■
“Remove a PCIe Card or Filler” on page 123
■
“Install a PCIe Card or Filler” on page 125
■
“Verify a PCIe Card” on page 127
PCIe Card Configuration
Note - Before installing PCIe cards, refer to the SPARC T8-2 Server Product Notes and
the documentation for each PCIe card for detailed information about known issues and
configuration limitations.
This server has eight PCI Express 3.0 slots that accommodate low-profile PCIe cards. All slots
support x8 PCIe cards. Four slots are also capable of supporting x16 PCIe cards:
■
All Slots – x8 electrical interface
■
Slots 1, 2, 7 and 8 – x16 electrical interface
To determine the slot in which to install a PCIe card, follow these guidelines:
1. Install cards that require a specific slot. Refer to the SPARC T8-2 Server Product Notes and
the documentation for each card to determine if there are slot requirements.
2. Install the first NMVe switch card in slot 1. Install a second NMVe switch card in slot 2.
3. Install the remaining cards so that the load on the server is balanced.
In general, install the biggest and hottest cards in the outside slots and work your way to the
middle, alternating sides to evenly distribute cooling.
■
Fill the PCIe slots in this sequence: 8, 1, 7, 2, 6, 3, 5, 4.
■
Place the cards in this order: Expansion cards, storage cards, network cards, other cards.
Servicing PCIe Cards 119
