NVMe Card Configuration
You can install one or two NVMe switch cards in the server to support your NMVe drives. Two
drives to support a redundant NMVe configuration. Use these tables and the labels on the NMVe
cable to properly connect the NMVe switch cards to the disk backplane.
TABLE 1
Single NMVe Card Configuration
DBP NVMe
Connector
NVMe Card
Connectors
(Slot 1)
3 3
2 2
1 1
0 0
TABLE 2
Dual NVMe Card Configuration
DBP NVMe Connector NVMe Card Connectors
(Slot 1)
NVMe Card Connectors
(Slot 2)
3 3
2 2
1 3
0 2
Related Information
■
“Remove a PCIe Card or Filler” on page 123
■
“Install a PCIe Card or Filler” on page 125
