2.各部の名称とはたらき
- 12 -
2.2 Functions of each part
①Engine switch
Insert the key and perform "START", "RUN" and "OFF" of the engine.
②Throttle lever
Adjust the Engine speed from "High speed" to "Low speed".
③ Choke lever
Used to start the engine in cold weather. If you pull it, it will be in the "closed" position,
and if you return it, it will be in the "open" position.
No action required if the engine is warm.
④Light switch for movement
Press to turn "ON (turn on, light on)" and press again to turn "OFF (off, light off)".
When the switch is "ON", the switch lights up in blue.
This light is for moving. Never use it for work.
There is a risk of collision, fall, etc. because the surrounding situation cannot be grasped.
Please drive at low speed when the light is on.
⑤Cutting height adjustment lever
This product can be set to any cutting height between 10 and 80 mm. Press the cutting height
lock button at the tip of the cutting height adjustment lever with your thumb, adjust the
height to your liking, and then release the lock button to fix the cutting height at that position
(see the figure below). As a guide for the cutting height when adjusting, align the lever
position with the scale label (* displayed in 10 mm increments) on the right side of the lever.
The engine will not start except in the "move" position. The knife height is different when the
knife is rotated and when it is stopped. (This is because the knife lifts up a little due to the
centrifugal force caused by high-speed rotation.) The scale is the value when the knife is
rotated in the test field. Please refer to it as the mowing height during actual mowing work.
(Slightly different depending on the field.)
Press the lock button firmly to the end to adjust the cutting height. If you operate press the
button while it is stopped halfway (half-pressed), it may cause a malfunction.安全のため、For
safety, be sure to set the cutting height adjustment lever to the "move" position when
entering, exiting, or moving backward in the work field.
