4.運転・作業のしかた
- 31 -
4) For safety, if the cutting height adjustment lever is returned to the "move" position, the knife clutch
lever will also be linked and returned to the "off" position., Its lifespan is significantly shortened.
Except in an emergency, please observe the operation method of 4.4 Mowing work.
5) The knife clutch lever cannot be operated when the cutting height adjustment lever is in the "move"
position.
6) Use the Speed change lever (change pedal) to perform normal stop operations. If you depress
the parking brake pedal in an emergency, this product will stop in an emergency, at this time, the
speed change lever (change pedal) returns to the neutral "N" position at the same time.
7) Be sure to stop the engine when you leave the machine, and be sure to remove the key and store it
by the owner.
4.5 Adjusting the handle / seat position according to work and physique
● Depending on the physique of the user, the handle can
be adjusted in 4 steps up and down, 4 steps back and
forth, and the seat can be slid back and forth to adjust.
① Seat slide back and forth
The seat position can be adjusted back and forth by
pulling the lever and sliding it according to the physique
of the worker.
② Handle up and down
When adjusting the handle height, remove the fixing bolt, adjust the handle height, insert the
fixing bolt, and then fix it with the U nut.
③ Handle front-back direction
The front-back (tilt) position of the handle can be adjusted in the front-back direction.
4.6 How to use the moving light
This light is for moving. Please do not use it for work.
The light switch is on the lower right side of the
steering wheel.
Press to "ON" and press again to move to the "OFF"
position. When "ON", the switch lights up in blue.
