5.1.5 Lubricate to each part
1) Grease about every 30 hours, and lubricate other parts with rust preventive / lubricant
as needed. In particular, if you neglect to lubricate the grease, it may cause damage
due to poor lubrication. Lubricate referring to the grease nipple part in the figure below.
Link pin (Front)
Link Pin (Rear)
Knife Shaft
Center pin / kingpin axis
Brake shaft
Pedal shaft
Knife tension shaft
