5. 点検・整備・調整
- 32 -
5. Inspection / maintenance / adjustment
5.1 Oil inspection / replacement / lubrication
1) Refer to the hour meter display on the meter panel of this product for a guideline for
checking, replacing, and lubricating oil in each part.
2) The machine is filled with oil at the time of shipment, but before using the machine for
the first time, be sure to check that the specified amount of oil is contained in the
specified part before using it.
3) Regular oil changes are a must to always keep your machine in top condition.
4) When inspecting or changing the oil in each part, be sure to place the machine on a wide
flat place, warm up the engine, stop it, and cool it to the extent that it is not hot to the
touch (about 5 minutes). Please wait before starting work.
…If you work immediately after stopping the engine…
※Each part of the engine body is very hot and there is a risk of burns.
※Immediately after the engine is stopped, oil still remains in the engine and each part
of the mission, and the exact amount of oil is not shown.
5) For safety, remove the key and keep it with the owner until the work is completed.
5.1.1 Inspection and replacement of mission oil
◎ Inspection / replenishment.
①
For inspection, remove the mission plug at the rear of the
mission case. If the mission oil can be visually confirmed
through the Mission plug port (up to the full port), almost
the specified amount of mission oil is contained.
The Mission plug port doubles as the oil inspection port.
◎ Exchange…
② For replacement, prepare an appropriate container to
receive the oil, and remove the drain plug (oil drain plug)
at the bottom of the left side of the mission case every
20 hours for the first time and 100 hours after that.。
