5. 点検・整備・調整
- 42 -
②Knife belt adjustment (under the seat bracket)
Visually inspect the belt for damage. If he has any
damage such as cracks or wear, replace it with a new
one.
③Belt retainer adjustment (under the seat bracket)
① Set the cutting height adjustment lever to a position of about 30 mm.
② Put the knife clutch lever in the "on" position。
③ Adjust the gap between each belt retainer by referring to the following.。
