Panasonic DP-8020E

204
SEP 2006
Ver. 1.0
DP-8020E/8020P/8016P
4.3.17. Scanned Copy Quality Problems
START
No
Yes
Is the Scanning Lamp
abnormal?
Replace the Scanning Lamp.
END
Are the Transmitting
Rollers dirty?
Are there any foreign particles,
or paper pieces in the scanning
area?
Yes
No
Remove the foreign particles, or paper
pieces from the scanning area.
No
Yes
Is the scanning area dirty?
1. Clean the Scanning Glass.
2. Clean Mirrors 1, and 2.
No
Yes
Clean the rollers.
Is the Scanner Block abnormal?
1. Check CN (SC PCB).
2. Check CN (CCD PCB).
3. Replace the CCD Assembly.
4. Replace the SC PCB.
Yes
No
