DP-8020E/8020P/8016P
8.6. Installing the Hard Disk Drive Unit (DA-HD18)
8.6.1. Contents
Note:
Refer to the Parts Manual for Part Number(s), Packing, and Accessories detail.
No. Qty. Description Remarks
1 1 Hard Disk Drive (HDD)
2 1 DC PCB
3 1 HDD Cover
4 1 HD Harness
5 1 HDD2 Harness
6 1 DC12 Harness
7 2 Harness Clamp (Small) Black
8 4 Harness Clamp (Medium) White
9 4 Screw (6-32 x 3/8)
10 6 Screw (M3 x 6)
11 1 Installation Instructions This document
1 2 3 4
5
6
7
8
9
10
11
