1.3. Fax, Printer and Internet Fax Functions
1.3.1. Fax Function
Items
Description
Remarks
DP-8020E DP-8020P
Main Specifications
1 Compatibility G3 ITU-T Std & Non-Std
2 PSTN Line Port Yes 1-Line Only
3 Leased Line Port No
4 V.24 Line Port No
5 Modem Speed 33.6 - 2.4 kbps T.30/V.34/V.17/V.29/V.27ter
6 Coding Scheme JBIG/MMR/MR/MH
7 ECM Yes Conforms to ITU-T Rec. T.30
ECM
8 Short Protocol Yes (B, D)
9 Transmission Speed
Approx. 2.9 sec
ITU-T Image No. 1
(A4, Std Resolution)
10
Communication Resolution
dpi x lpi (pels/mm x lines/
mm)
Transmission
Std. : 203 x 98 (8 x 3.85)
Fine : 203 x 196 (8 x 7.7)
S-Fine : 203 x 391 (8 x 15.4)
406 x 391 (16 x 15.4)
600dpi : 600 x 600 dpi
Reception
Std. : 203 x 98 (8 x 3.85)
Fine : 203 x 196 (8 x 7.7)
S-Fine : 203 x 391 (8 x 15.4)
406 x 391 (16 x 15.4)
600dpi : 600 x 600 dpi
600 dpi communication is only
possible between T.30 Compliant
Panafax, WORKiO, and other
T.30 compliant machines.
Scanner Mechanism
1 Scanning Device CCD (ADF / Platen)
2 Scanning Speed (ADF)
Resolution Vertical Horizontal
LTR / A4, Scanned in Vertical or
Horizontal Direction.
Excluding Initializing Time and
ADF slipping factor.
Std: 203 x 98 (8 x 3.85)
dpi x lpi (pels/mm x lines/
mm)
0.9 / 1.0 sec 0.7 sec
Fine: 203 x 196 (8 x 7.7)
dpi x lpi (pels/mm x lines/
mm)
S-Fine: 406 x 391 (16 x
15.4) dpi x lpi (pels/mm x
lines/mm)
1.8 / 2.0 sec 1.4 sec
600dpi: 600 x 600 2.8 sec 2.1 sec
3 Scanning Speed (Platen)
Resolution Vertical Horizontal
600dpi: 600 x 600 2.8 sec 2.1 sec
4
Scanning Resolution
dpi x lpi (pel/mm x lines/
mm)
Std. : 203 x 98 (8 x 3.85)
Fine : 203 x 196 (8 x 7.7)
S-Fine : 203 x 391 (8 x 15.4)
406 x 391 (16 x 15.4)
600dpi : 600 x 600 dpi
