Panasonic DP-8020E

57
SEP 2006
Ver. 1.0
DP-8020E/8020P/8016P
(50) Remove the Snap Ring (B9).
(51) Remove the Bushing (698).
(52) Remove the Feed Roller (2010).
<Cleaning the Rollers, and Rubber>
(1) Open the ADF Cover.
(2) Release the Stopper.
(3) Clean the Separation Rubber, Feed Roller, Pre
Feed Roller, and Paper Feed Roller with a soft
cloth, saturated with Water.
<Cleaning the Exit Roller>
(1) Lift the Original Tray.
(2) Clean the Exit Roller with a soft cloth, saturated
with Water.
