95
SEP 2006
Ver. 1.0
DP-8020E/8020P/8016P
(28) Disconnect all the Harnesses on the PS PC
Board.
(29) Release the Harnesses from Harness Clamps.
(30) Remove 2 Screws (X3).
(31) Remove the PS PC Board Assembly.
(32) Remove 3 Screws (Y3), and 3 Screws (X3).
(33) Remove the PS Bracket (802).
(34) Remove 9 Screws (Y3).
(35) Remove the PS PC Board (2901).
To Next Page
